Goobay
Sat Multiswitch 5 Inputs/16 Outputs
distributor for a max. of 16 subscribers from one satellite
Goobay
Sat Multiswitch 5 Inputs/16 Outputs
distributor for a max. of 16 subscribers from one satellite
Article details
The multiswitch is your easy solution for connecting several devices for TV and radio reception in the same house via just one satellite dish. The switch ensures that each of the 16 subscribers can enjoy their individual programme - for superior flexibility in TV reception.
  • For connecting a single LNB, e.g. to the Astra, Hotbird, Eutelsat or Türksat satellite
  • With an integrated 22 kHz generator and suitable for both Quattro LNBs and Quad LNBs
  • Provides an individual reception signal to all connected subscribers - simultaneously and without interference
  • Supports HDTV, 3D, HD, 4K, 8K UHD and Sky and has 1x terrestrial input for DAB, DAB+, FM, DVB-T and DVB-T2 antennas
  • With modern electronics and a short-circuit-proof 230 V power supply unit (Europlug) for low power consumption, even in standby mode
  • Excellent transmission characteristics due to frequency-dependent amplification, very low signal loss and a high-quality metal housing to protect against interference
Technical specifications
Device connections
max. subscriber
16 szt.
Input, type
F female x in
Output, type
F female
switching commands
13/0; 18/0; 13/22; 18/22
Input Voltage
230 V (AC)
number of inputs
5 pcs.
Number of outputs
16 ports
Signal transmission
Frequency range
950 - 2.150 MHz
Frequency range terrestrial
47 - 862 MHz
Polarization decoupling SAT
28 - 30 dB
Output level SAT
100 dBµV
Transmission modes
DVB-S, DVB-S2, DVB-T, DVB-T2
Return loss SAT inputs
10 dB
Return loss SAT outputs
8 dB
Output level terr.:
88 dBµV
Reverse flow damping terrestrial Inputs
8 dB
Return loss terrestrial outputs
8 dB
Impedance
75 Ω
General
Color
silver, grey
Material
metal, plastic
Markings
CE, WEEE
Operating temperature from
0 °C
Operating temperature up to
50 °C
Packaging type
White Box with Label
Dimensions / Weight
Width
335.2 mm
Height
55.1 mm
depth
133 mm
Weight
840 g
Consumption Unit
1 pc. in cardboard box
Downloads
Packing units:
1 / 10
Item: 64876
EAN: 4040849648762
