LED Transformer 12 V (DC)/12 W
12 V (DC) for LEDs up to 12 W total load, not dimmable
LED Transformer 12 V (DC)/12 W
12 V (DC) for LEDs up to 12 W total load, not dimmable
Article details
- The electronic transformer supplies devices such as LED luminaires with a maximum power of 12 W at a voltage of 12 V.
- Its compact design and low weight make the LED driver the ideal power source for light strips, LED lamps, LED strips and under-cabinet luminaires.
- The LED power supply converts 230 V input voltage (AC) into 12 V output voltage (DC).
- The DC transformer measures 49 x 56 x 25 mm and is suitable for round lamp housings, flush-mounted boxes and switch boxes.
- The LED power supply unit is particularly safe thanks to overvoltage, overload and short-circuit protection and safe electronic isolation according to appliance class II.
- The small transformer is suitable for indoor and outdoor use thanks to protection class IP67.
- The housing made of sturdy plastic is equipped with two mounting holes.
Technical specifications
ErP
Average active efficiency
73 %
Performance
Dimmability
not dimmable
max. performance
12 W
max. performance
12.0 W
No-load power consumption
0.2 W
Device connections
Input, Voltage Range
220 - 240 (AC) V
Input, type
Loose cable ends 2 pin x in
Output, type
Loose cable ends 2 pin
Output, max. amperage
1 A
Output, voltage (DC)
12 V (DC)
number of inputs
2 pcs.
Input Cross Section
0.75 mm²
Output Cross Section
0.324 mm²
Number of outputs
2 ports
Output, voltage (DC)
12.0 V (DC)
Output, max. amperage
1.0 A
Input current
0.4 A
General
protection class
IP67
Appliance Class
II
Color
white
Markings
WEEE, CE
Special feature
Overload protection, short circuit protection
Operating temperature from
-20 °C
Operating temperature up to
45 °C
Packaging type
Retail Box
Dimensions / Weight
Length
49 mm
Width
25 mm
Height
50.5 mm
Weight
99.5 g
Consumption Unit
1 pc. in cardboard box
accessory - Power supply
Power frequency
50 Hz
Language Scope
Operation manual
de, en, fr, es, it, nl, pl, se, da, cz
packaging
de, en, fr, it, es, nl, da, sv, pl, cs
Downloads
Packing units:
1 / 50 / 100
Item: 59575
EAN: 4040849595752
