Goobay
Series 2.0
HDMI™ Splitter 1 to 2 (4K @ 60 Hz)
splits 1x HDMI™ input signal into 2x HDMI™ output signals
Goobay
Series 2.0
HDMI™ Splitter 1 to 2 (4K @ 60 Hz)
splits 1x HDMI™ input signal into 2x HDMI™ output signals
Article details
  • The HDMI™ splitter duplicates 1x HDMI™ input signal to up to 2x HDMI™ outputs such as TV set, monitor or projector.
  • The HDMI™ multi connector mirrors audio and video signals to the connected devices, e.g. for simultaneous projection in different rooms.
  • The HDMI™ splitter box 1x2 supports resolutions up to 4K @ 60 Hz (backward compatible).
  • The LED display of the HDMI™ extender indicates which connections are activated.
  • HDMI™ adapter 1 in 2 out in a flat design, equipped with heat-dissipating aluminium housing and gold-plated connectors.
  • Plug & Play allows for an easy connection without the need to install additional drivers.
  • Powered via 5 V power supply unit and Micro-USB cable (both included in the scope of delivery).
Technical specifications
Labelling
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Device connections
Input, type
HDMI™ female (Type A)
Output, type
2x HDMI™ female (Type A)
Signal transmission
4K Ultra HD 2160p (60 Hz)
supported audio standards
Dolby Atmos, Dolby Digital HD (DTS HD), Dolby Digital TrueHD, Dolby Digital 5.1 (AC-3), Dolby 5.1, Dolby 7.1, LPCM, Stereo, Enhanced Audio Return Channel (eARC), Audio Return Channel (ARC)
other supported standards
HDCP 2.2, HDCP 1.4
max. transmission rate
18 Gbit/s
max. resolution
4K Ultra HD 2160p (60 Hz), 4K Ultra HD 2160p (30 Hz), Full HD 1080p (60 Hz), Full HD 1080i (60 Hz), 3D, HDCP 2.2
product.attribute.techdat-signaltransmission-signaldirection
unidirektional
General
product.attribute.techdat-general-goobay-version
2.0
Color
black
Operating temperature from
0 °C
Operating temperature up to
40 °C
Packaging type
Bulk
Dimensions / Weight
Length
109 mm
Width
47.4 mm
Height
9.5 mm
Weight
71 g
Consumption Unit
1 pc. in cardboard box
Scope of delivery
Scope of delivery
manual, power supply
Language Scope
Operation manual
en, de, fr, it, es, nl, da, se, pl, cz
£35.99 RRP
Packing units:
1 / 50
Item: 58481
EAN: 4040849584817
